Mini Industrial 4 - port 10 / 100TX 802.3at PoE + 1- Port 100TX Ethernet Switch

Brand Name : E-link

Model Number : LNK-IMC005P

Certification : CE,FCC,Rohs

Place of Origin : China

MOQ : 1pcs

Price : Negotiated

Payment Terms : T/T, PayPal

Supply Ability : 1000pcs/month

Delivery Time : 3-5 working days

Packaging Details : Industrial Ethernet Switch standard export package

Packet Buffer : 512K bits

Casing : Aluminum Case

Packet Length : 2046bytes

Mounting Options : DIN-Rail / Wall-mount

Operating Temperature : -40°C to 80°C (-40°F to 176°F)

Storage Temperature : -40°C to 85°C (-40°F to 185°F)

Contact Now

Mini Industrial 4-port 10/100TX 802.3at PoE + 1-Port 100TX Ethernet Switch

Mini Industrial PoE Switch Advantages

► 5 x 10/100 BASE-TX ports

► 4 10/100BASE-TX Fast Ethernet RJ45 copper ports with IEEE 802.3at PoE+ Injector (Port-1 to Port-4)

► 12~48VDC wide range power input

► Supports 802.3x Flow control

► Supports DIN-Rail and Wall-mount installation

► Up to 120-watt PoE budget (48VDC), 90-watt PoE budget (24VDC), 60-watt PoE budget (12VDC)

► Industry standard design, dustproof and close design IP40, rugged high-strength metal case

► -40°C to 80°C (-40°F to 176°F) operating temperature

Overview

LNK-IMC005P Series is a Mini Industrial 4-port 10/100TX 802.3at PoE+1-Port 100TX Ethernet Switch

with 12~48VDC wide range power input. This unmanaged industrial Ethernet switch is designed to match

the critical industrial standards. With reliable and simple operation against vibration and shock, and wide

operation temperature range, it could match a variety of harsh environment. The switch complies with CE

and FCC standards, and passed the 100% burning test to ensure that it will fulfill the needs of industrial

applications. It is a good choice for an economical solution for industrial Ethernet connections.
Mini Industrial PoE Switch Picture

Mini Industrial 4 - port 10 / 100TX 802.3at PoE + 1- Port 100TX Ethernet Switch
Technical Indexes

Ethernet
Standards: IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE 802.3at Power over Ethernet Plus PSE
IEEE 802.3af Power over Ethernet Plus
Forward & Filtering Rate: 14,880pps (10Mbps)
148,800pps (100Mbps)
Packet Buffer: 512K bits
Packet Length: 2046bytes
MAC Address Table: 2K
Switch Fabric: 1Gbps/non-blocking
Exchange Property

Backplane bandwidth: 20Gbps;

Packet forwarding rate: 14.88Mpps

Connector:

5 10/100BASET RJ45

4 ports with 802.3at PoE+ injector function (Ports 1 to 4)

PoE (Power over Ethernet)
Standard: IEEE802.3af/at
Port: RJ45
Power Pin Assignment 4/5(+), 7/8(-)
PoE Budget: Up to 120-watt PoE budget (48VDC), 90-watt PoE budget (24VDC), 60-watt PoE budget (12VDC)
Environmental
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
MTBF > 200,000 hrs

Application
Mini Industrial 4 - port 10 / 100TX 802.3at PoE + 1- Port 100TX Ethernet Switch
Ordering Information

Model Description
LNK-IMC005P Mini Industrial 4-port 10/100TX 802.3at PoE+1-Port 100TX Ethernet Switch
Mounting Options ► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
Power Options ► Power Supply is to be purchased separately
